产品编号Model Number

LZB55L

LZB60L

LZB80L

额定载重 load capacity

kg

5500

6000

8000

载荷中心load center

mm

600

600

800

起升高度lifting height

mm

110

110

110

爬坡度（空载）Ascend slope ability (without load )

%

8

8

8

爬坡度（满载）Ascend slope ability (with load )

%

5

5

5

自重（含电池）Weight (with battery)

kg

≈905

≈940

≈1020

整车长度Overall length

mm

2600

2602

2750

整车宽度Overall width）

mm

876

876

876

轴距Wheelbase

mm

1490

1490

1580

货叉长度Fork length

mm

1150

1150

1300

货叉外宽Fork outside width

mm

750

750

900

货叉最低高度Fork lowered height

mm

100

100

150

最小离地间隙Min ground height

mm

5

5

15

最小直角通道宽度Min.right-angle stacking channel width

mm

2500

2500

2650

带踏板最小转弯半径Min。 turning radius (with platform)

mm

2190

2190

2500
