产品编号Model Number |
LZB8015 |
|
额定载重Rated Capacity (Q) |
kg |
1500 |
载荷中心Load Center (C) |
mm |
600 |
货叉最大高度Max Fork Height (H4) |
mm |
200 |
货叉最低高度Min Fork Height (H3) |
mm |
85 |
手柄高度Handle Height (H1) |
mm |
1200 |
货叉尺寸Fork Size (1xn) |
mm |
1150x160 |
货叉外宽Fork Width (E) |
mm |
570 (680) |
转弯半径Min. Turning Radius (Wa) |
mm |
1450 |
轮距Wheel Base (Y) |
mm |
1270 |
前轮规格Front-Wheel Distance (X) |
mm |
200 |
最大行驶速度/空载Max. speed without load |
km/h |
4~5 |
最大行驶速度/满载Max. speed with load |
km/h |
3.5~4 |
最大爬坡度Max.travel Grade |
% |
8~10 |
驱动电机Driving Motor |
v/kw |
24/0.65 |
提升电机Lifting Motor |
v/kw |
24/0.8 |
电机Battery |
v/Ah |
12x2/60 |
充电器Charger |
v/A |
24/10 |
整机长度Overall Length (A) |
mm |
1630 |
整机宽度Overall Width (B) |
mm |
700 |
整机高度Overall Height (C) |
mm |
1200 |
整机重量Overall Net Weight |
kg |
220 |
