产品编号Model Number |
LSD2501 |
LZDS1025 |
LZDS1029 |
|
额定载荷Rated Capacity |
kg |
250 |
500 |
1000 |
载荷中心Load Center |
mm |
400 |
500 |
600 |
货叉高度Fork Height |
mm |
90-1560 |
90-1560 |
88-1550 |
货叉长度Fork Length |
mm |
800 |
1000 |
1150 |
货叉外宽Fork Width |
mm |
150-690 |
160-690 |
540 |
最小转弯半径Min.Turning Radius |
mm |
1075 |
1075 |
1250 |
前轮尺寸Front wheel size |
mm |
Φ80×94 |
Φ80×94 |
Φ80×94 |
后轮尺寸Rear wheel size |
mm |
Φ150×40 |
Φ150×40 |
Φ150×50 |
整机长度Overall Length |
mm |
1325 |
1325 |
1600 |
整机宽度Overall Width |
mm |
725 |
725 |
725 |
整机高度Overall Heigth |
mm |
2030 |
2030 |
1930 |
整机重量Overall Net Weight |
kg |
140 |
146 |
|
