产品编号Model Number | LZC1310 | LZC1510 | |
额定载重 Load Capacity | kg | 1300 | 1500 |
载荷中心Load Center | mm | 600 | 600 |
门架净高Gantry height | mm | 4510 | 4510 |
起升高度Lifting Height | mm | 10000 | 10000 |
门架最大高度Max. Height of the gantry | mm | 11070 | 11070 |
护顶架高度Overhead Guard Height | mm | 2461 | 2461 |
座椅高Seat height | mm | 1210 | 1210 |
货叉规格Fork specification | mm | 45/120/1200 | 45/120/1200 |
货叉标准Fork standard | 2/A | 2/A | |
叉架板宽度Fork plate width | mm | 880 | 880 |
货叉最大宽度Maximum width of fork | mm | 845 | 845 |
最小离地间隙Minimum Ground Clearance | mm | 90 | 90 |
直角堆垛通道宽度 Right angle stacking channel width | mm | 4015 | 4335 |
转弯半径Turning radius | mm | 2175 | 2500 |
行驶速度 空载/满载Driving speed No load/full load | mm | 10/10 | 10/10 |
起升速度 空载/满载Lifting speed no load/full load | 380/320 | 380/320 | |
下降速度 空载/满载Falling speed no load/full load | 480/460 | 480/460 | |
驱动电机额定功率Drive motor rated power | 10 | 10 | |
起升电机额定功率Lifting motor rated power | 12 | 12 | |
蓄电池Battery | v/Ah | 80/500 | 80/700 |
轮胎材料Tire material | 聚氨酯 | 聚氨酯 | |
轮胎尺寸Tire size | mm | 285x100/285x108 | 285x100/285x108 |
轮胎尺寸(驱动)Tire size (drive) | mm | 400x160 | 400x160 |
行车制动Service brake | 液压制动 | 液压制动 | |
驻车制动Parking brake | 电磁制动 | 电磁制动 | |
旋转角度Rotation angle | 180 | 180 | |
侧移速度Side shift speed | mm/s | 240 | 240 |
控制器类型Controller type | 交流 | 交流 | |
转向类型Steering type | 电子转向 | 电子转向 | |
整车长度Vehicle length | mm | 3428 | 3788 |
整车宽度Vehicle width | mm | 1580 | 1580 |
工作通道宽度Working channel width | mm | 1600 | 1600 |
蓄电池重量Battery Weight | kg | 1322 | 1877 |
整车自重(含电池)Vehicle weight (with battery) | kg | 5500 | 7710 |
