产品编号Model Number | LZD2901 | LZD2902 | LZD2903 | LZD2904 | |
额定负载Load capacity |
kg | 500 | |||
载荷中心Load center |
mm | 300 | |||
货叉最低高度Min. height of fork |
mm | 40 | |||
总高整机高度Overall Height |
2080 | 1580 | 1850 | 2080 | |
最大提升高度Max. lifting height |
mm | 1600 | 2000 | 2500 | 3000 |
设备最大时高度Max. Machine Height |
2080 | 2540 | 3040 | 3540 | |
货叉尺寸 Fork Size LxWxH |
mm | 600/760x80X25(宽度可选) | |||
货叉外宽Outer fork width |
mm | 600 | |||
转弯半径Turning radius |
mm | 1060 | |||
最小离地间隙Minimum ground clearance |
mm | 30 | |||
轮距Wheel Base |
mm | 940 | |||
电池Battery |
V/Ah | 2x12/100 | |||
驱动电机Driving Motor |
kw | 0.7 | |||
起升电机Lifting Motor |
kw | 2 | |||
升降速度(空载/满载)Lifting speed (no load / full load) |
mm /s | 120/85 | |||
最大爬坡度Maximum grade |
% | 5 | |||
整机长度Overall Length |
mm | 2000 | |||
整机宽度Overall Width |
mm | 820 | |||
整机自重Total Weight |
kg | 650 |
