产品编号Model Number | LZDB1016 | LZDB1516 | LZDB2016 | |
额定载重Full Load (Q) |
kg | 1000 | 1500 | 2000 |
载荷中心Load Center (C) |
mm | 400 | 400 | 400 |
货叉最大高度Max. Fork Height (H) |
mm | 1600 | 1600 | 1600 |
货叉长度Fork Length (L) |
mm | 1000 | 1000 | 1000 |
货叉宽度Fork Width (E) |
mm | 300-850 | 320-850 | 320-850 |
最小转弯半径Min. Turning Radius(R) |
mm | 1350 | ||
轴距Whell Base (Y) |
mm | 1180 | ||
前轮距Front Wheel Distance (X) |
mm | 322 | ||
起升电机Lifting Motor |
v/kw | 12/1.6 | ||
蓄电池Battery |
v/Ah | 12/120 | ||
充电器Charger |
v/A | 12/15 | ||
整机长度Overall Length (A) |
mm | 1670 | ||
整机宽度Overall Width (B) |
mm | 865 | ||
整机高度Overall Height (H1) |
mm | 2060 | ||
整机重量Overall Net Weight |
kg | 350 | 365 | 390 |
