产品编号Model Number | LZDB1020 | LZDB1025 | LZDB1030 | LZDB1035 | |
额定载重Full Load (Q) |
kg | 1000 | 1000 | 1000 | 1000 |
载荷中心Load Center (C) |
mm | 400 | 400 | 400 | 400 |
货叉最大高度Max. Fork Height (H) |
mm | 2000 | 2500 | 3000 | 3500 |
设备最大高度Max. Machine Height | mm | 2560 | 3060 | 3560 | 4060 |
货叉长度Fork Length (L) |
mm | 1000 | |||
货叉宽度Fork Width (E) |
mm | 300-850 | |||
最小转弯半径Min. Turning Radius(R) |
mm | 1350 | 1350 | 1450 | 1450 |
轴距Whell Base (Y) |
mm | 1185 | |||
前轮距Front Wheel Distance (X) |
mm | 316 | |||
起升电机Lifting Motor |
v/kw | 12/1.6 | |||
蓄电池Battery |
v/Ah | 12/120 | 12/120 | 12/120 | 12/150 |
充电器Charger |
v/A | 12/15 | |||
整机长度Overall Length (A) |
mm | 1660 | |||
整机宽度Overall Width (B) |
mm | 865 | 865 | 930 | 930 |
整机高度Overall Height (H1) |
mm | 1580 | 1830 | 2080 | 2330 |
整机重量Overall Net Weight |
kg | 425 | 450 | 470 | 500 |
