| 产品编号Model Number | GZ785801 | |
| 安全工作载荷Lift Rated Capacity | kg | 230 |
| 延伸平台工作载荷Lifting extend capacity | kg | 113 |
| 最大工作高度Maximum working height | m | 7.8 |
| 最大平台高度Max.Platform Height | m | 5.8 |
| 整机长度Overall Length | m | 1.86 |
| 整机宽度Overall Width | m | 0.76 |
| 整机高度(围栏未折叠) Folding maximum height (guardrail unfolding) | m | 2.18 |
| 整机高度(围栏折叠)Folding maximum height (guardrail removed) | m | 1.84 |
| 工作平台尺寸Platform size | m×m | 1.67×0.74 |
| 平台延伸尺寸Platform exten size | m×m | 0.90×0.74 |
| 最小离地间隙（收拢状态）Minimum ground clearance(folding) | m | 0.09 |
| 最小离地间隙（起升状态）Minimum ground clearance(rising) | m | 0.019 |
| 轴距 Wheel Base | m | 1.38 |
| 最小转弯半径（内轮）/ Minimum turn radius(inner wheel) | m | 0 |
| 最小转弯半径（外轮）/Minimum turn radius(outer wheel) | m | 1.64 |
| 驱动电机 Driving Motor | v/kw | 24V/0.5kw |
| 起升电机 Lifting Motor | v/kw | 24V/2kw |
| 机器行使速度（收拢状态/）Running speed(folding) | km/h | 6km/h |
| 机器行使速度（起升状态）/Running speed(rising) | km/h | 0.8km/h |
| 上升/下降速度/Rising/falling speed | sec | 27/22 |
| 蓄电池 | v/Ah | 4×6V/185Ah |
| 充电器 | v/a | 24V/25A |
| 最大爬坡能力/Maximum climbing ability | % | 25% |
| 工作最大允许角度/Maximum working allowable angle | o | 2/3 |
| 轮胎 Wheel Size | mm | ￠305×100 |
| 整机重量Overall Net Weight | kg | 1240 |
