产品编号/Model Number | GZ030520 | GZ060820 | GZ759520 | GZ091120 | |
平台最大高度/Max.Platform Height | mm | 3000 | 6000 | 7500 | 9000 |
工作最大高度Maximum working height | 5000 | 8000 | 9500 | 11000 | |
平台最低高度/Min.Platform Height | mm | 850 | 980 | 1250 | 1500 |
平台尺寸/Platform Size | mm | 1300*700 | 1800*880 | 1800*1000 | 1800*1000 |
额定载重/Lift Rated Capacity | Kg | 500 | 500 | 500 | 500 |
上升时间/Elevating Time | s | 16S | 54S | 72S | 83S |
电压电源/Voltage | v/hz | 380V/50 | 380V/50 | 380V/50 | 380V/50 |
电机功率/Electromotor Power | kw | 0.75 | 1.1 | 1.5 | 1.5 |
整机长度/Overall Length | mm | 1450 | 2000 | 2000 | 2000 |
整机宽度/Overall Width | mm | 900 | 1080 | 1200 | 1200 |
整机高度/Overall Height | mm | 980 | 980 | 1250 | 1500 |
设备净重/Overall Net Weight | Kg | 400 | 650 | 1100 | 1260 |
规格型号/Model Number | GZ111320 | GZ121420 | GZ141620 | GZ161820 | |
平台最大高度/Max.Platform Height | mm | 11000mm | 12000mm | 14000mm | 16000mm |
平台最低高度/Min.Platform Height | mm | 1600mm | 1700mm | 1800mm | 1980mm |
平台尺寸/Platform Size | mm | 2100*1150 | 2450*1350 | 2450*1350 | 2700*1500 |
额定载重/Lift Rated Capacity | Kg | 500kg | 500kg | 500kg | 300kg |
上升时间/Elevating Time | s | 88S | 90s | 120S | 130s |
电压电源/Voltage | v/hz | 380V/50 | 380V/50 | 380V/50 | 380V/50 |
电机功率/Electromotor Power | kw | 2.2 | 3 | 3 | 3 |
整机长度/Overall Length | mm | 2250 | 2600 | 2600 | 2850 |
整机宽度/Overall Width | mm | 1350 | 1550 | 1550 | 1750 |
整机高度/Overall Height | mm | 1600 | 1600 | 1800 | 2000 |
设备净重/Overall Net Weight | Kg | 1380 | 1850 | 2500 | 2680 |
