产品编号/Product number | GZ080615 | GZ100815 | GZ121015 | GZ141215 |
最大工作高度Maximum working height | 8m | 10m | 12m | 13.8m |
最大平台高度Maximum platform height | 6m | 8m | 10m | 11.8m |
整机高度(护栏立起)Folding maximum height(guardrail unfolding) | 2.21m | 2.34m | 2.47m | 2.59m |
整机高度(护栏折叠)Folding maximum height(guardrail removed) | 1.75m | 1.86m | 1.99m | 2.17m |
整机宽度Overall Width | 0.81m | 1.15m | 1.15m | 1.15m |
整机长度Overall Length | 2.48m | 2.48m | 2.48m | 2.48m |
平台尺寸Platform size | 2.27x0.81m | 2.27x1.12m | 2.27x1.12m | 2.27x1.12m |
平台延伸长度Platform extend size | 0.9m | 0.9m | 0.9m | 0.9m |
额定载荷Lifting capacity | 380kg | 450kg | 320kg | 320kg |
最大允许风速Maximum wind speed | 12.5m/s | 12.5m/s | 12.5m/s | 12.5m/s |
轴距Wheelbase | 1.87m | 1.87m | 1.87m | 1.87m |
最小回转半径(外侧)Minimum turn radius(outer wheel) | 2.10m | 2.20m | 2.20m | 2.20m |
最小回转半径(内侧)Minimum turn radius(inner wheel) | 0m | 0m | 0m | 0m |
最小离地间隙(收拢)Minimumground clearance(folding) | 10cm | 10cm | 10cm | 10cm |
最小离地间隙(起升)Minimumground clearance(rising) | 1.9cm | 1.9cm | 1.9cm | 1.9cm |
整机重量Whole weight | 1980kg | 2380kg | 2690kg | 2980kg |
蓄电池Battery | 4x6v/225AH | 4x6v 225AH | 4x6v/225AH | 4x12v/150AH |
控制方式Way of control | 电液比例控制Electro-hydraulic proportion control | |||
最大工作压力Maximum working pressure | 240Bar | 240Bar | 240Bar | 240Bar |
电源电压Power Voltage | 24v | 24v | 24v | 24v |
轮胎尺寸Wheel size | 381x127mm | 381x127mm | 381x127mm | 381x127mm |
最大爬坡定值Maxinum climbing ability | 25% | 25% | 25% | 25% |
最大允许倾斜角度Maxinum working allowable angle | X-2,Y-3 | X-2,Y-3 | X-2,Y-3 | X-2,Y-3 |
行驶速度(收拢状态)Running speed(folding) | 4.5km/h | 4.0km/h | 4.0km/h | 4.0km/h |
行驶速度(起升状态)Running speed(rising) | 0.8km/h | 0.8km/h | 0.8km/h | 0.8km/h |
