| 产品编号 Model Number | 单位 | GZ080621 | GZ100821 | GZ121021 | GZ141221 |
| 最大工作高度/Maximum working height | mm | 8000 | 10000 | 12000 | 14000 |
| 最大平台高度/Maximum platform height | mm | 6000 | 8000 | 10000 | 11800 |
| 额定载荷/Lifting capacity | kg | 320 | 320 | 320 | 320 |
| 工作平台尺寸/Platform Size | mm | 2270×1150 | 2270×1150 | 2270×1150 | 2270×1150 |
| 工作延伸尺寸/Platform extend size | mm | 900 | 900 | 900 | 900 |
| 最小离地间隙（收拢状态）Minimum ground clearance(folding) | mm | 110 | 110 | 110 | 110 |
| 最小离地间隙（起升状态）Minimum ground clearance(rising) | mm | 20 | 20 | 20 | 20 |
| 轴距/Wheelbase(E) | mm | 1850 | 1850 | 1850 | 1850 |
| 最小转弯半径（内轮）/ Minimum turn radius(inner wheel) | mm | 0 | 0 | 0 | 0 |
| 最小转弯半径（外轮）/Minimum turn radius(outer wheel) | mm | 2100 | 2100 | 2100 | 2100 |
| 电机功率/Power source | v/kw | 24/3 | 24/3 | 24/3 | 24/3 |
| 机器行使速度（收拢状态/）Running speed(folding) | km/h | 3.5 | 3.5 | 3.5 | 3.5 |
| 机器行使速度（起升状态）/Running speed(rising) | km/h | 0.8 | 0.8 | 0.8 | 0.8 |
| 上升/下降速度/Rising/falling speed | sec | 40/50 | 40/50 | 70/80 | 70/80 |
| 蓄电池/Battery | V/Ah | 4×6/210 | 4×6/210 | 4×6/210 | 4×6/210 |
| 充电器/Charger | V/A | 24/25 | 24/25 | 24/25 | 24/25 |
| 最大爬坡能力/Maximum climbing ability | % | 20 | 20 | 20 | 20 |
| 工作最大允许角度/Maximum working allowable angle | / | 2-3° | 2-3° | 2-3° | 2-3° |
| 控制方式/Way of control | / | 电液比例控制Electro-hydraulic proportion control | |||
| 驱动/Driver | / | 双前轮Double front-wheel | |||
| 液压制动/Hydraulic drive | / | 双后轮Double rear-wheel | |||
| 轮台尺寸（实心无痕）/Wheel size(stuffed&no mark) | / | Φ381×127 | Φ381×127 | Φ381×127 | Φ381×127 |
| 收起时最大高度（栏杆立起）Folding maximum height(guardrail unfolding) | mm | 2150 | 2275 | 2400 | 2525 |
| 收起时最大高度（栏杆拆除）Folding maximum height(guardrail removed) | mm | 1190 | 1315 | 1440 | 1565 |
| 整机长度Overall Length(C) | mm | 2400 | 2400 | 2400 | 2400 |
| 整机宽度Overall Width | mm | 1150 | 1150 | 1150 | 1150 |
| 整体重量Whole weight | kg | 1900 | 2080 | 2490 | 2760 |
