产品编号Model Number | GW060804 | GW081004 | GW101204 | GW121404 | |
平台最大高度Max.Platform Heig | mm | 6000 | 8000 | 10000 | 12000 |
最大工作高度Maximum working heig | mm | 8000 | 10000 | 12000 | 14000 |
安全工作载荷Lift Rated Capacity | kg | 300 | 300 | 250 | 200 |
工作平台尺寸Platform Size | mm | 1210×600 | 1210×600 | 1450×600 | 1450×600 |
最小离地间隙Ground clearance | mm | 80 | 80 | 80 | 80 |
轴距 Wheel Base | mm | 1170 | 1170 | 1420 | 1420 |
后轮 Rear Wheel | φ200×50mm | φ200×50mm | φ200×50mm | φ200×50mm | |
前轮 Front Wheel | φ180×50mm | φ180×50mm | φ180×50mm | φ180×50mm | |
起升电机Lifting Motor AC | v/kw | AC/1.5kw | AC/1.5kw | AC/1.5kw | AC/1.5kw |
起升电机Lifting Motor DC | v/kw | 12VDC/2.5kw | 12VDC/2.5kw | 12VDC/2.5kw | 12VDC/2.5kw |
蓄电池Battery | v/Ah | 2×12V/150Ah | 2×12V/150Ah | 2×12V/150Ah | 2×12V/150Ah |
充电器Charger | v/A | 12V/15A | 12V/15A | 12V/15A | 12V/15A |
整机长度Overall Length | mm | 1560 | 1560 | 1790 | 1840 |
整机宽度Overall Width | mm | 840 | 840 | 840 | 840 |
整机高度Overall Heig | mm | 1860 | 1860 | 1860 | 2080 |
整机重量Overall Net Weig | kg | 570 | 630 | 730 | 825 |
备注 Note | 标准机器为交流电源220V可选配交直流两用、直流电源 |
