产品编号Model Number

GW0907G

GW1109G

平台高度Max. Platform Heigh

mm

7500

9000

工作高度Max. Machine height

mm

9000

10500

平台最低高度Min. Platform Height

mm

680

680

最小离地间隙Ground clearance

mm

20

20

额定载荷Lift Rated Capacity

kg

220

150

平台尺寸Platform size

mm

1000x700x1100

行驶速度（平台未起升）Max. Drive Speed (platform Stowed)

km/h

3~4

行驶速度（平台起升）Max.Drive Speed (platform Elevated)

km/h

0.6~1

转弯半径Minimum turn radius

mm

1800

最大爬坡能力Max. Climbing Capacity

%

20

车轮尺寸Wheel Size

in

Φ 305x100

驱动电机Driver Motor

v/kw

2x2.4/0.5

起升电机Lifting Motor

v/kw

24/2.2

蓄电池Battery

v/Ah

2x12/150

电压Charger

v/A

24/15

坑洞保护Pothole protection system

/

Mechanical control

整机长度Overall Length

mm

1700

整机宽度Overall Width

mm

1000

整机高度Overall Height

mm

2000

2100

整机重量Overall Net Weight

kg

1100

1250
